Canon XA70 UHD 4K30 Camcorder with Dual-Pixel Autofocus

Large-Sensor Image Quality in a Compact Professional Camcorder

The Canon XA70 combines a large 1-inch 4K CMOS sensor, DIGIC DV 6 processing, a versatile 15x optical zoom, and Canon’s Dual Pixel CMOS AF in a compact professional camcorder. Its larger sensor provides excellent image quality, improved low-light performance, and greater control over depth of field.

With professional XLR audio, dual SD card slots, infrared recording, XF-AVC and MP4 formats, and HD streaming through USB-C, the XA70 is well suited for weddings, events, houses of worship, education, corporate production, documentary work, and legal applications.

🎥 Key Features

• 1-inch 4K UHD CMOS sensor

• Canon DIGIC DV 6 image processor

• UHD 4K recording at up to 30p

• Oversampled Full HD recording

• Integrated 15x optical zoom lens

• Wide 25.5–382.5mm-equivalent zoom range

• Canon Dual Pixel CMOS AF

• Face Detection and Face Tracking

• Five-axis Dynamic Image Stabilization

• Built-in three-density ND filter system

• XF-AVC and MP4 recording formats

• Dual SD memory-card slots

• Relay and simultaneous recording

• Detachable professional handle unit

• Two XLR audio inputs

• Four-channel linear PCM audio

• Infrared recording with built-in IR light

• 3.5-inch touchscreen LCD

• Tilting OLED electronic viewfinder

• UVC streaming through USB-C

• On-screen display time-stamp recording

• Mini-HDMI output

✨ Large 1-Inch 4K Sensor

The XA70’s 1-inch CMOS sensor provides approximately 8.29 effective megapixels for native 4K UHD recording. Compared with smaller camcorder sensors, its larger imaging area offers improved low-light performance, reduced noise, and greater control over background separation.

Canon’s DIGIC DV 6 processor delivers natural color and detailed images in both 4K and Full HD.

🔭 Wide-Angle 15x Optical Zoom

The integrated Canon lens covers approximately 25.5–382.5mm in 35mm-equivalent terms. Its wide end is useful for interiors, groups, establishing shots, and working in confined spaces, while the telephoto end provides ample reach for ceremonies, presentations, performances, and sporting events.

The lens features an F2.8–4.5 maximum aperture, nine-blade iris, and 58mm filter thread. Zoom can be controlled using the body rocker, handle rocker, touchscreen, or manual lens ring.

🎯 Dual Pixel CMOS Autofocus

Canon’s Dual Pixel CMOS AF provides smooth, fast, and accurate focusing across approximately 80% of the image area.

Touch AF allows the operator to select a subject directly on the 3.5-inch LCD, while Face Detection and Face Tracking maintain focus on speakers, performers, and interview subjects. AF-Boosted Manual Focus combines manual control with automatic focus confirmation, and the Dual Pixel Focus Guide assists precise manual focusing.

🖐️ Five-Axis Image Stabilization

The XA70 combines optical lens-shift stabilization with electronic correction to reduce camera shake. Dynamic IS provides five-axis stabilization for handheld and walking shots, while Standard and Powered IS modes support general shooting and long-telephoto work.

🌤️ Built-In ND Filters

A motorized neutral-density filter system provides three strengths:

• ND 1/4

• ND 1/16

• ND 1/64

These filters help control exposure in bright conditions while allowing the operator to maintain a preferred shutter speed or wider aperture.

🎞️ XF-AVC and MP4 Recording

The XA70 records in professional XF-AVC or widely compatible MP4 formats.

• XF-AVC records 4K UHD at up to 160 Mbps

• MP4 records 4K UHD at up to 150 Mbps

• Full HD is available at up to 60p

• Slow and Fast Motion modes provide additional creative options

Oversampled HD processing uses information from the 4K sensor to produce detailed Full HD footage.

🎙️ Professional XLR Audio

The included detachable handle unit provides two XLR inputs with professional microphone and line-level controls. Phantom power is available for compatible condenser microphones, and four-channel linear PCM recording supports multiple audio sources when properly configured.

The handle also incorporates a microphone holder, accessory shoe, secondary zoom control, record trigger, tally lamp, and infrared light.

Separate 3.5mm microphone and headphone connections provide additional input and monitoring options.

💾 Dual SD Card Slots

Two SD memory-card slots can be configured for:

• Simultaneous recording to both cards for backup

• Relay recording for longer uninterrupted sessions

• Flexible recording arrangements for different production needs

🌙 Infrared Recording

Infrared mode allows the XA70 to record in extremely dark environments. The detachable handle includes an infrared light for recording when normal visible illumination is unavailable or inappropriate.

This feature is useful for documentaries, wildlife, legal work, security applications, and nighttime event coverage.

💻 USB-C Streaming and HDMI Output

The XA70 can stream HD video through USB-C using the UVC standard when connected to a compatible Windows or Mac computer. This allows the camcorder to serve as a streaming camera without a separate capture device.

A mini-HDMI connection provides video output for monitors, recorders, switchers, and other production equipment. The XA70 does not include the 3G-SDI output found on the otherwise similar XA75.

A compatible USB-C cable is required for streaming and sold separately. Audio is not transmitted through the UVC USB output.

🕒 On-Screen Time-Stamp Recording

On-Screen Display recording can permanently embed information such as date, time, and timecode into the video image. This is valuable for legal, law-enforcement, inspection, documentary, and evidentiary applications.

📦 What’s Included

• Canon XA70 professional camcorder

• Detachable handle unit

• Microphone holder

• Canon BP-820 rechargeable battery

• Canon PD-E1 USB power adapter

• AC power cable

• Lens hood with integrated lens barrier

• Limited one-year manufacturer warranty

SD memory cards and USB streaming cable are sold separately.
